Resolution Phenolic Pipe Support
Accumen produces high-quality Pipe Supports using Austrotherm Resolution 120kg/m³ premium-performance phenolic foam, factory-faced with an aluminium foil vapour barrier. This product is among the most thermally efficient solutions for insulating pipework in building services and HVAC applications, capable of performing across an extensive temperature range from +120°C to -180°C.
Designed to minimize the effects of thermal bridging caused by pipe suspension systems, it helps maintain the overall energy efficiency of pipework.
Resolution Phenolic Pipe Supports are free of chlorides and halogenated fire retardants, making it the ideal choice for insulating stainless steel pipework where the risk of CUI is a concern.
In addition to its superior thermal performance, Resolution Phenolic Pipe Supports deliver exceptional fire safety, achieving a Group 1S rating to ISO 9705 and full compliance with AS/NZS 1530.3 and AS 1366.2:1992 fire performance standards. These features ensure zero flame spread and negligible smoke development, making it a safe and dependable choice for the most demanding environments.
Accumen maintains ample stock of Resolution Phenolic Pipe Supports and can manufacture to order with exceptionally quick lead times, ensuring timely delivery to meet project requirements. No project is too large or too small, making Accumen a trusted partner for insulation needs across a wide range of applications.
Designed to meet diverse performance requirements, the product is available in various thicknesses and is compatible with mild steel, stainless steel, carbon steel, copper, and plastic pipework.
Accumen can supply Resolution Phenolic Pipe Supports in higher density, ranging up to 320kg/m3 for specialized Pipe Support applications.
-
Accumen’s Resolution Phenolic Pipe Supports are engineered to deliver exceptional thermal efficiency, thanks to its low aged thermal conductivity. This characteristic makes it one of the most thermally efficient insulation materials commonly used in the market today.
Enhanced Energy Efficiency: The low thermal conductivity ensures minimal heat transfer, resulting in superior insulation performance. This significantly reduces energy loss in pipe systems, improving overall operational efficiency.
Space-Saving Design: A key advantage of the material’s low thermal conductivity is that it allows specified thermal performance standards to be achieved with much thinner insulation compared to other materials. This not only conserves space but also reduces the overall weight of the insulated system, simplifying installation and handling.
Long-Term Performance Stability: The aged thermal conductivity remains consistently low over time, ensuring sustained insulation performance throughout the product's lifecycle.
These attributes make Resolution Phenolic Pipe Insulation a preferred choice for applications where thermal efficiency, space constraints, and long-term reliability are critical.
-
Description Resolution Phenolic Pipe Support products are designed to deliver exceptional fire performance, ensuring safety and compliance across a wide range of applications.
Group 1S Rating (ISO 9705): These products achieve a Group 1S classification, the highest possible rating for fire performance under the ISO 9705 Room Corner Test. This rating demonstrates excellent resistance to flame spread and very low smoke production, making them suitable for use in critical environments where fire safety is paramount.
Compliance with AS/NZS 1530.3: Resolution Phenolic Pipe Support products easily meet the stringent requirements of the AS/NZS 1530.3 standard, which assesses materials for:
Ignitability: Minimal tendency to ignite.
Spread of Flame: Extremely low spread, reducing fire propagation risks.
Heat Evolved: Low heat release during exposure to fire.
Smoke Developed: Minimal smoke generation, ensuring visibility and safety in the event of a fire.
These attributes, combined with its exceptional thermal insulation properties, make Resolution Phenolic Pipe Supports an outstanding choice for projects that prioritize fire safety alongside energy efficiency.
-
Resolution Phenolic Pipe Supports stand out as an environmentally responsible insulation solution due to its impressive sustainability attributes. The manufacturing process utilises a blowing agent that is entirely free of CFCs and HCFCs, substances known to deplete the ozone layer. This ensures the foam achieves a zero Ozone Depletion Potential (ODP), making it a safer choice for the environment compared to traditional insulation materials.
In addition, Resolution Phenolic Pipe Supports boast a low Global Warming Potential (GWP), meaning its overall contribution to greenhouse gas emissions during production and use is significantly minimized. This aligns with global efforts to combat climate change by reducing the carbon footprint associated with building materials.
Beyond its manufacturing process, the foam's closed-cell, fibre-free structure enhances its thermal efficiency and durability, eliminating issues such as air infiltration. By preventing thermal bridging and maintaining consistent insulation performance over time, it contributes to long-term energy savings, further reducing environmental impact by decreasing the energy demands of heating and cooling systems.
These attributes collectively position Resolution Phenolic Pipe Supports as a sustainable choice for environmentally conscious construction and industrial applications.
-
Resolution Phenolic Pipe Supports feature a 95% or greater closed-cell structure, which plays a critical role in its superior performance. This high closed-cell content ensures the material is non-wicking, meaning it resists absorbing water even in high-moisture environments. This characteristic makes the insulation highly resistant to moisture penetration, a vital attribute for maintaining its thermal integrity and long-term performance.
